Details:
-
High Efficiency means more POWER while keeping TEMP low!
-
4 pole rotor design for stronger torque, the motor has strong explosive force.
-
Compared with the previous generation of motors, the output power and efficiency are increased by more than 4%, and the motor temperature is effectively reduced under the same load.
-
0.2mm thick silicon steel laminations, high strength explosion-proof rotor,high-temperature resistant coil, and imported high-precision and high-quality bearings make the motor super durable.
| KV | 4500KV or 6500KV |
| Lipo Cells | 2S |
| No-load Current (A) | 2.1A / 4500kv. | 3.4A / 6500kv |
| Dia/Length | φ=24mm(0.94") L=36mm(1.42") |
| Shaft Dia / Length | φ=2mm(0.08") L=12mm(0.47") |
| Bearing size | D8*D3*T4 |
| Pole | 4 |
| Weight | 61.2g |
| Applications | 1/16&1/18 On-road, Off-road |
